A 3-hour emergency DALI self-test driver designed for constant current LED devices, supplied complete with extra long life LiFePO4 battery packs. This product is suitable for integral applications. The ADM/1 operates a single 4V chip at 700mA. In keeping with the DALI standard, this unit will revert to standalone self-test if not connected to a DALI operating system. For a full list of our compatible devices, please see our LED Device range. This range operates with LiFePO4 battery technology, dramatically reducing energy consumption and facilities management labour due their long operational life.
Specifications
- For Integral Use with Slim Batteries
- DALI-2 Certified Device
- High Temperature Tolerance Batteries
- Extra Long Life LiFePO4 Batteries
- DALI Self-Test Module
- High Output (700mA)
- LiFePO4 Automatic Battery Protection and Recovery
| ADM/1 | |
| Input Voltage | 230-240 Volts AC – 50/60Hz |
| Power Rating | Charging Maintained: 5W 28mA λ = 0.74Standby Non-Maintained: 0.3W 8mA λ = 0.15 |
| Em. Duration | 3-hours |
| Battery Type | IFpR27/67 LiFePO4 |
| Battery Voltage | 3.2V |
| Battery Capacity | 3.8Ah |
| Charge Current | 225mA nominal |
| Discharge Current | 700mA nominal |
| Recharge Time | 24-hours |
| TC Max | 60°C Module / 55°C Battery |
| Output Load | 1 x 3W |
| Output Current | 700mA |
| Module Dims. | 135mm x 30mm x 21mm |
| Battery Dimensions | 90mm long x 24mm wide x 28mm high |
| Fixing Centres | 132mm x M4 |
| Module Weight | 0.1Kg |
| Battery Weight | 0.11Kg |
