Wattage:
Voltage:
EAN:
Manufacturer:
Built-in active PFC function, PF>0.9 for 75% of load or higherBuilt-in constant current limiting circuit (C.V + C.C mode)Protections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 295 VAC) / Full rangeIP67 ratedClass 2 power unit / Pass LPSCooling by free air convection Suitable for LED lighting, street lighting and moving sign applicationsMeet 4KV surge immunity level (IEC 61000-4-5)3 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 60 Output Voltage 36V Dimmable (Type) No DC Output Adjustment Fixed . Can be modified between 90%~110% Dimensions 172 x 61.5 x 39 EMC Standards EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~295VAC, 127~417VDC Safety Standards UL1310, UL8750, UL879, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single PDF Datasheet CLG-60-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 60 Output Voltage 36V Dimmable (Type) No DC Output Adjustment Fixed . Can be modified between 90%~110% Dimensions 172 x 61.5 x 39 EMC Standards EN55015, EN55022 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~295VAC, 127~417VDC Safety Standards UL1310, UL8750, UL879, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13 Output Voltage Options Single PDF Datasheet CLG-60-SPEC.PDF
