Wattage:
Voltage:
EAN:
Manufacturer:
The Ecopac Power ECP100-24VF-1 slimline constant voltage LED driver is ideal for concealment where space is restricted, such as hiding behind a strip. Short circuit, over temperature and over loading protection are all standard features.
Ecopac Power LED Drivers are supplied with a 3 year warranty.
Other features:
Slim line LED Driver
Universal AC input/ Full range 180-264VAC
Input Frequency 50/60Hz
24V Constant voltage output
3 years warranty
More Information Manufacturer Ecopac Power Output Wattage (W) 100 Output Voltage 12V Dimmable (Type) No DC Output Adjustment N/a Dimensions 320.6x 26.8x 18.2 (LxWxH) mm EMC Standards EN55015, EN61000-3-2; EN61000-3-3; EN61547 Input Voltage 180-264VAC Safety Standards EN61347-1,EN61347-2-13 Working Temperature -20~+45°C PDF Datasheet ECP-100-VF-1.pdf
More Information Manufacturer Ecopac Power Output Wattage (W) 100 Output Voltage 12V Dimmable (Type) No DC Output Adjustment N/a Dimensions 320.6x 26.8x 18.2 (LxWxH) mm EMC Standards EN55015, EN61000-3-2; EN61000-3-3; EN61547 Input Voltage 180-264VAC Safety Standards EN61347-1,EN61347-2-13 Working Temperature -20~+45°C PDF Datasheet ECP-100-VF-1.pdf
