Wattage:
Voltage:
EAN:
Manufacturer:
Product features
- Compact casing shape
Functions
- Selectable current output by dip-switch
Electrical features
- Mains voltage: 220–240 V ±10%
- Mains frequency: 50–60 Hz
- Push-in terminals: rigid 0.5–1.5 mm² strand 0.75–1.5 mm²
- Power factor at full load: > 0.95
- Open circuit voltage (Umax.): 60 V
- Secondary side switching of LED modules is not allowed
Safety features
- Protection against transient main peaks up to 1 kV (between L and N)
- Electronic short-circuit protection
- Overload protection
- Degree of protection: IP20
- Protection class II
- SELV
Dimensions
- Length: 97 mm • Width: 43 mm • Height: 30 mm
Product guarantee
- 5 years for operation at recommended operation temperature
