0-10V/ Potentiometer/10V PWM dimmableConstant voltage designUniversal AC input/ Full rangeIP66 design for indoor or outdoor installationsProtections: Short circuit/ Overload/ Over voltage/ Over temp.Built-in PFC function (PFC>0.98)Cooling by free air convectionOver 83% efficiency
More Information Manufacturer Ecopac Power Output Wattage (W) 20 Dimmable (Type) 0-10V, Potentiometer, 10V PWM dimmable Dimensions 140x 45x 27mm EMC Standards Compliance to EN55015, EN61000-3-2 (>60%load), Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry level (surge 4KV) Criteria A Input Voltage 100-265VAC Safety Standards EN61347-1 EN61347-2-13 Output Voltage Options Single Working Temperature -40-+80°C PDF Datasheet ELED-20-V_Series.pdf
More Information Manufacturer Ecopac Power Output Wattage (W) 20 Dimmable (Type) 0-10V, Potentiometer, 10V PWM dimmable Dimensions 140x 45x 27mm EMC Standards Compliance to EN55015, EN61000-3-2 (>60%load), Compliance to EN61000-4-2,3,4,5,6,11, EN61547, light industry level (surge 4KV) Criteria A Input Voltage 100-265VAC Safety Standards EN61347-1 EN61347-2-13 Output Voltage Options Single Working Temperature -40-+80°C PDF Datasheet ELED-20-V_Series.pdf
