ELED-40-C300/1400DP2 Features:
40W DALI 2 and Push Dimming Multiple-Stage Output Current LED Driver
Features:
• Constant Current mode output with multiple levels selectable by dip switch
• DALI 2 dimming function (IEC62386)
• AC input: 100-277VAC
• Built-in active PFC function
• Efficiency up to 86%
• Protections: Short circuit/ Over load/Over temperature
• Cooling by free air convection
• Suitable for intelligent LED lighting
| Wattage | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 40 | 39 | 35.8 | 32.5 | 29.3 | 26 | 22.8 | 19.5 |
| Input Voltage | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 100~277VAC | 300mA |
| Output Current | 1400mA | 1300mA | 1200mA | 1100Ma | 1000mA | 900mA | 800mA | 700mA | 650mA | 600mA | 550mA | 500mA | 450mA | 400mA | 350mA | 3~65 |
| Output Voltage | 3~29 | 3~31 | 3~34 | 3~37 | 3~40 | 3~45 | 3~50 | 3~57 | 3~62 | 3~65 | 3~65 | 3~65 | 3~65 | 3~65 | 3~65 | |
| Dimensions | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm | 171.5 x 54x 20 mm |
| Working Temperature | -40~80°C | |||||||||||||||
| Safety Standards | EN61347-1, EN61347-2-13, UL8750 | |||||||||||||||
| EMC Standards | Compliance to EN55015, EN61000-3-2,3 (≥50% load), FCC Part 15B | |||||||||||||||
