Wattage:
Voltage:
EAN:
Manufacturer:
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage AC
198…264 V
Power factor λ
0.95
Efficiency in full-load
88 %
Device power loss
8.2 W
Inrush current
< 25 A
Max. ECG no. on circuit breaker 10 A (B)
10
Max. ECG no. on circuit breaker 10 A (C)
16
Max. ECG no. on circuit breaker 16 A (B)
15
Max. ECG no. on circuit breaker 16 A (C)
26
Max. ECG no. on circuit breaker 25 A (B)
24
Surge capability (L-N)
1 kV
Nominal output voltage
24 V
Nominal output power
60 W
Maximum output power
60 W
Galvanic isolation primary/secondary
3 kV
Output ripple Voltage (100 Hz)
< 3 %
Dimensions & weight
Mounting hole spacing, length
192 mm
Product weight
296.00 g
Cable cross-section, input side
0.75…1.5 mm²
Cable cross-section, output side
0.75…1.5 mm²
Wire preparation length, input side
5.0 mm
Width
40.0 mm
Height
31.0 mm
Length
200.0 mm
Colors & materials
Casing material
Plastic
Temperatures & operating conditions
Ambient temperature range
-20…+50 °C
Maximum temperature at tc test point
85 °C
Max.housing temperature in case of fault
110 °C
Temperature range at storage
-40…+85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
30000 h
Additional product data
Predecessor EAN
4052899528680, 4052899463790
Capabilities
Dimmable
No
Overheating protection
Yes
Overload protection
Yes
Short-circuit protection
Yes
Intended for no-load operation
No
Suitable for fixtures with prot. class
I / II
Number of channels
1
Certificates & standards
Approval marks – approval
CE / RCM / CCC / MM
Standards
Acc. to IEC 61347-1/Acc. to IEC 61347-2-13/Acc. to IEC 62384/Acc. to IEC 61000-3-2/Acc. to CISPR 15/Acc. to IEC 61000-3-3/Acc. to IEC 61547
Type of protection
IP20
Logistical data
Commodity code
850440839000
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration
19-10-2022
Primary Article Identifier
4052899605527
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
9094d77e-5439-4549-8aef-7667bfd9f7fe
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
|---|---|---|---|---|---|
| 4052899605527 | UNV
|
1 | 200mm x 40mm x 31mm | 296.00g | 0.25dm³ |
| 4052899605534 | VS
|
30 | 421mm x 225mm x 141mm | 9493.00g | 13.36dm³ |
