Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Very low power loss thanks to high efficacy
- Protective operation throughout the entire partial-load range for long lamp life
Areas of application
- Effect and accent lighting
- Living rooms
- Object lighting
- Conference rooms
- Restaurants
- Recessed and surface-mounted furniture luminaires
- Shop lighting
- Event rooms
-
Technical Data
Electrical data
Lamp wattage
20…70 W
Maximum output power
70 W
Line current
0.30 A
Nominal voltage
220…240 V
Power factor λ
0.95
Operating frequency
50 kHz
Nominal output voltage
11.9 / 12.0 V
Input voltage AC
198…264 V
Mains frequency
50…60 Hz
System wattage
74.00 W
Efficiency in full-load
94 %
Input voltage range
220…240 V
Max. ECG no. on circuit breaker 10 A (B)
37
Max. ECG no. on circuit breaker 16 A (B)
59
Galvanic isolation primary/secondary
4.00 kV
Inrush current
0.45 A
Dimensions & weight
Length
128.0 mm
Width
38.0 mm
Height
31.0 mm
Mounting hole spacing, length
119.0 mm
Cable cross-section, input side
0.75 mm²
Cable cross-section, output side
0.75 mm²
Wire preparation length, input side
12 / 6.0 mm
Wire preparation length, output side
12 / 6.0 mm
Product weight
115.00 g
Temperatures & operating conditions
Ambient temperature range
0…+45 °C
Maximum temperature at tc test point
70 °C
Additional product data
Design / version
Compact
Capabilities
Dimming method
Trailing- or leading-edge phase control for inductive load dimmers
Overload protection
Automatic reversible
Overheating protection
Automatic reversible
Short-circuit protection
Automatic reversible
Max. cable length to lamp/LED module
2.0 m
Cable/wire types, input side
H03VV-F 2x0.75 mm²
Cable/wire types, output side
H03VV-F 2x0.75 mm²
Dimmable
Yes
Dimming range
0…100 %
No-load proof
Yes
Suitable for fixtures with prot. class
II
Intended for no-load operation
No
Certificates & standards
Approval marks – approval
VDE / EAC
Standards
Acc. to EN 61347/Acc. to EN 55015/Acc. to EN 61000-3-2/Acc. to EN 61547
Type of protection
IP20
