Wattage:
Voltage:
EAN:
Manufacturer:
Constant Power mode output
Metal housing design
Full Power at 70~100% max. current
Built-in active PFC function
No load power consumption <0.5W
IP67 rating for indoor or outdoor installations
Output current adjustable via potentiometer
3 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Current 1850mA Dimmable (Type) No Output Voltage Range (V) 30 ~ 54V DC Output Adjustment 1300~ 3000mA Dimensions 180x53x33mm (LxWxH) EMC Standards Compliance to EN55015, EN61000-3-2 Class C (load?70%) ; EN61000-3-3,GB17743,GB17625.1,EAC TP TC 020 Input Voltage 180 ~ 295VAC 254 ~ 417VDC Safety Standards LVD EN61347-1,EN61347-2-13 Independent, GB19510.1,GB19510.14,EAC TP TC 004,IP67 approved Output Voltage Options Single Working Temperature -30 ~ +90°C PDF Datasheet FDLC-100-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Current 1850mA Dimmable (Type) No Output Voltage Range (V) 30 ~ 54V DC Output Adjustment 1300~ 3000mA Dimensions 180x53x33mm (LxWxH) EMC Standards Compliance to EN55015, EN61000-3-2 Class C (load?70%) ; EN61000-3-3,GB17743,GB17625.1,EAC TP TC 020 Input Voltage 180 ~ 295VAC 254 ~ 417VDC Safety Standards LVD EN61347-1,EN61347-2-13 Independent, GB19510.1,GB19510.14,EAC TP TC 004,IP67 approved Output Voltage Options Single Working Temperature -30 ~ +90°C PDF Datasheet FDLC-100-spec.pdf
