Wattage:
Voltage:
EAN:
Manufacturer:
Output voltage and constant current level can be adjusted through internal potentiometer.
IP65 rated
Protections: Short circuit / Over current / Over voltage / Over temperature
Other features:
Universal AC input (up to 305VAC) / Full range
High efficiency up to 95%
Output current adjustable through output cable or internal potentiometer
Cooling by free air convection
Suitable for LED lighting and street lighting applications
Meet 4KV surge immunity level (IEC61000-4-5)
Multiple models for choice:
Built-in active PFC function, PF>0.9 for 60% of load or higher
IP65 rated
5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 240 Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment +/-6% rated output voltage Dimensions 244.2 x 68 x 38.8 EMC Standards EN55015, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~305VAC, 127~431VDC Safety Standards UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13, UL1012, UL60950-1, TUV EN60950-1 Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-240H-spec_7.pdf
More Information Manufacturer Mean Well Output Wattage (W) 240 Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment +/-6% rated output voltage Dimensions 244.2 x 68 x 38.8 EMC Standards EN55015, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 90~305VAC, 127~431VDC Safety Standards UL8750, TUV EN61347-1, EN61347-2-13, PSE J61347-1, J61347-2-13, UL1012, UL60950-1, TUV EN60950-1 Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-240H-spec_7.pdf
