Io adjustable through built-in potentiometer and environment adaptiveness
Constant current design
Metal housing with class I design
Protections: Short circuit / Over voltage / Over temperature
Other features:
IP65 design for indoor or outdoor installations
Output adjustable via potentiometer
Typical lifetime >62000 hours
7 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 320.25 Output Current 1050mA Dimmable (Type) Potentiometer Output Voltage Range (V) 311 Dimensions 252x 90x 43.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (@ load >50%) ; EN61000-3-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV) Input Voltage 90-305VAC 127-431VDC Safety Standards UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent; IP65 or IP67 approved Output Voltage Options Single Working Temperature Tcase= -40~+85°C (Refer to “Output load vs temperature” section of the datasheet) PDF Datasheet HLG-320H-C-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 320.25 Output Current 1050mA Dimmable (Type) Potentiometer Output Voltage Range (V) 311 Dimensions 252x 90x 43.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C (@ load >50%) ; EN61000-3-3 Compliance to EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge immunity Line-Earth 4KV, Line-Line 2KV) Input Voltage 90-305VAC 127-431VDC Safety Standards UL8750 (type”HL”); CSA C22.2 No. 250 13-12; ENEC EN61347-1, EN61347-2-13 independent; IP65 or IP67 approved Output Voltage Options Single Working Temperature Tcase= -40~+85°C (Refer to “Output load vs temperature” section of the datasheet) PDF Datasheet HLG-320H-C-SPEC.PDF
