Wattage:
Voltage:
EAN:
Manufacturer:
IP67 design for indoor or outdoor installationsBuilt-in active PFC, PF>0.9 for 60% of load or higher5 years warrantyProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 305VAC) / Full rangeHigh efficiency up to 90.5%Output current adjustable through output cableCooling by free air convectionBuilt-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)Suitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Class 2 power unit
More Information Manufacturer Mean Well Output Wattage (W) 40 Output Voltage 24V Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment -0 EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~305VAC, 127~431VDC Safety Standards UL8750, TUV EN61347-1, EN61347-2-13 approved; Design refer to UL60950-1, EN60950-1, EN60335-1 Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-40H-spec_4.pdf
More Information Manufacturer Mean Well Output Wattage (W) 40 Output Voltage 24V Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment -0 EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~305VAC, 127~431VDC Safety Standards UL8750, TUV EN61347-1, EN61347-2-13 approved; Design refer to UL60950-1, EN60950-1, EN60335-1 Output Voltage Options Single Working Temperature -40~+70°C PDF Datasheet HLG-40H-spec_4.pdf
