Wattage:
Voltage:
EAN:
Manufacturer:
Built-in 3 in 1 dimming function (1~10VDC, PWM signal, or resistance)Built-in active PFC, PF>0.9 for 60% of load or higher5 years warrantyProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Universal AC input (up to 305VAC) / Full rangeHigh efficiency up to 94%Output current adjustable through output cable or internal potentiometerCooling by free air convectionSuitable for dry, damp and wet locationSuitable for LED lighting and street lighting applicationsMeet 4KV surge immunity level (IEC61000-4-5)Class 2 power unitIP67 design for indoor or outdoor installations
More Information Manufacturer Mean Well Output Wattage (W) 80 Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment +/-10% rated output voltage EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~305VAC, 127~431VDC Output Voltage Options Single Working Temperature -40~+50°C PDF Datasheet HLG-80H-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 80 Dimmable (Type) 1-10VDC, PWM signal, resistance DC Output Adjustment +/-10% rated output voltage EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, EN55024 Input Voltage 90~305VAC, 127~431VDC Output Voltage Options Single Working Temperature -40~+50°C PDF Datasheet HLG-80H-spec.pdf
