Wattage:
Voltage:
EAN:
Manufacturer:
High efficiency • Uniform distribution of light • Good to excellent color rendering • Long lifetime • Hot restrike capable • UV values significantly below the maximum permitted thresholds to IEC 61167 thanks to UV filter
• Foyers, reception areas • Factory and hall lighting with low-cost installations • Exhibition halls and trade fairs • Sports halls and multi-purpose halls • Pedestrian zones, public squares • Parks and gardens • Buildings, monuments, bridges • Approved only for use in enclosed luminaires • Outdoor applications only in suitable luminaires
Technical Data
Electrical data
Nominal wattage
250.00 W
Rated wattage
250.00 W
Lamp current
3.0 A
PFC capacitor at 50 Hz
32 µF
Nominal voltage
98 V
Ignition voltage
4.0 kVp;25 kVp
Nominal current
3 A
Photometrical data
Rated lamp efficacy (standard condition)
80 lm/W
Rated luminous flux
20000 lm
Color rendering index Ra
88
Color temperature
4200 K
Light color
842
Rated LLMF at 2,000 h
0.80
Rated LLMF at 4,000 h
0.75
Rated LLMF at 6,000 h
0.65
Rated LLMF at 8,000 h
0.55
Rated LLMF at 12,000 h
0.50
UV protection
Yes
Nominal luminous flux
20000 lm
Rated color temperature
4200 K
Luminous flux
20000 lm
Light color (designation)
Neutral White DE LUXE
Dimensions & weight
Diameter
25.0 mm
Length
162.0 mm
Light center length (LCL)
81.0 mm
Product weight
52.00 g
Overall length
162.0 mm
Outer bulb
T25
Temperatures & operating conditions
Maximum permitted outer bulb temperature
650 °C
Maximum permitted pinch temperature
300 °C
Lifespan
Rated lamp survival factor at 2,000 h
0.95
Rated lamp survival factor at 4,000 h
0.90
Rated lamp survival factor at 6,000 h
0.85
Rated lamp survival factor at 8,000 h
0.80
Rated lamp survival factor at 12,000 h
0.50
Lifespan B50
12000 h
Additional product data
Base (standard designation)
Fc2
Design / version
clear
Mercury content
12.0 mg
Appropriate disposal acc. to WEEE
Yes
Mercury-free
No
Capabilities
Dimmable
No
Burning position
p45
Enclosed luminaire required
Yes
Hot restart
Yes
Certificates & standards
Energy efficiency class
A
Energy consumption
275 kWh/1000h
Country specific categorizations
ILCOS
MD/UB-250/842-H/E/SL-Fc2-25/162/H
Order reference
HQI-TS 250W/NDL
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
|---|---|---|---|---|---|
| 4008321766878 | FLH
|
1 | 52mm x 52mm x 260mm | 70.00g | 0.70dm³ |
| 4008321766885 | VS
|
12 | 216mm x 166mm x 272mm | 984.00g | 9.75dm³ |
