Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Very low power consumption thanks to high efficiency
- Through-wiring possible on the primary side
- Large temperature range
- Protective operation throughout the entire partial-load range for long lamp life
Areas of application
- Effect and accent lighting
- Living rooms
- Object lighting
- Conference rooms
- Restaurants
- Recessed and surface-mounted ceiling luminaires
- Shop lighting
- Event rooms
Technical Data
Electrical data
Lamp wattage
35…105 W
Maximum output power
105 W
Line current
0.45 A
Input voltage DC
176…275 V
Nominal voltage
230…240 V
Power factor λ
0.95
Operating frequency
40 kHz
Nominal output voltage
11.6 / 11.4 V
Mains frequency
50…60 Hz
System wattage
108.00 W
Efficiency in full-load
95 %
Max. ECG no. on circuit breaker 10 A (B)
23
Galvanic isolation primary/secondary
4.00 kV
Max. ECG no. on circuit breaker 16 A (B)
38
Networked standby power
0.50 W
Inrush current
0.6 A
Dimensions & weight
Length
170.0 mm
Width
44.0 mm
Height
34.0 mm
Wire preparation length, input side
8.0 mm
Wire preparation length, output side
8.0 mm
Mounting hole spacing, length
140.0 mm
Product weight
160.00 g
Temperatures & operating conditions
Ambient temperature range
-20…+50 °C
Maximum temperature at tc test point
75 °C
Additional product data
Design / version
Long with cable clamp
Capabilities
Dimming method
Phase cut-off
Dimming interface
DALI or Touch DIM/Touch DIM Sensor
Overload protection
Automatic reversible
Overheating protection
Automatic reversible
Short-circuit protection
Automatic reversible
Max. cable length to lamp/LED module
2.0 m
Cable/wire types, input side
H03VV-F 2x0.50 / H03VV-F 2x0.75 / H03VVH2-F 2x0.75 / H05VVH2-F 2x0.75 / H05VV-F 2x2.5 / H05VV5G 1.5 / NYM-O 2x1.5 / NYM-J 3x1.5 / NYM-J 5x1.5 mm²
Cable/wire types, output side
H03VV-F 2x0.75 / H05VV-F 2x0.75 / H05VV-F 2x1.5 / H05VV-F 2x2.5 / NYM-J 3x1.5 / NYM-J 3x2.5 / NYM-O 2x1.5 mm²
Dimmable
Yes
Dimming range
0.1…100 %
No-load proof
Yes
Intended for no-load operation
No
Certificates & standards
Approval marks – approval
E1 approval / VDE / VDE-EMC
Standards
Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547/Acc. to EN 61347-2-2
Type of protection
IP20
Logistical data
Commodity code
850440909000
Environmental information
Date of Declaration
10-11-2021
Primary Article Identifier
4008321420633
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
1b7fa333-bfff-4d5d-a686-eec22e4e177d
