Wattage:
Voltage:
EAN:
Manufacturer:
Wide input range 180~528VACHigh efficiency up to 91.5%Built-in active PFC functionProtections: Short circuit / Over current / Over voltage / Over temperatureOther features:Cooling by free air convection3 in 1 dimming function (0~10Vdc, 10V PWM signal or resistance)IP67 design for indoor or outdoor installationsSuitable for LED lighting and street lighting applicationsCompliance to worldwide safety regulations for lightingSuitable for dry / damp / wet locations5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 150 Output Voltage 15V DC Output Adjustment 13.5~17 Dimensions 245x 68x 38.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, FCC part 15 class B, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A Input Voltage 180~528VAC 254VDC~747VDC Safety Standards UL8750, CSA C22.2 No. 250.0-08, IP67 approved Output Voltage Options Single Working Temperature -40 ~ +70? (Refer to "Derating Curve") PDF Datasheet HVG-150-spec.pdf
More Information Manufacturer Mean Well Output Wattage (W) 150 Output Voltage 15V DC Output Adjustment 13.5~17 Dimensions 245x 68x 38.8 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, FCC part 15 class B, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A Input Voltage 180~528VAC 254VDC~747VDC Safety Standards UL8750, CSA C22.2 No. 250.0-08, IP67 approved Output Voltage Options Single Working Temperature -40 ~ +70? (Refer to "Derating Curve") PDF Datasheet HVG-150-spec.pdf
