Wattage:
Voltage:
EAN:
Manufacturer:
Output voltage and C.C level can be adjusted through internal potentiometerBuilt-in active PFC5 years warrantyProtections: Short circuit / Over voltage / Over temperatureOther features:High efficiency up to 92%Cooling by free air convectionConstant current designOutput current adjustable through output cable or internal potentiometerSuitable for dry, damp and wet locationsSuitable for LED lighting and street lighting applicationsIP65 design5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Current 3500mA Dimmable (Type) 1-10VDC, PWM signal, resistance Output Voltage Range (V) 29~285 EMC Standards Design refer to EN55015, FCC part 15 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 180~528VAC, 254~747VDC Safety Standards Design refer to UL8750, TUV EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30~+60°C (Refer to "Derating Curve") PDF Datasheet HVGC-100-spec_4.pdf
More Information Manufacturer Mean Well Output Wattage (W) 100 Output Current 3500mA Dimmable (Type) 1-10VDC, PWM signal, resistance Output Voltage Range (V) 29~285 EMC Standards Design refer to EN55015, FCC part 15 class B, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 180~528VAC, 254~747VDC Safety Standards Design refer to UL8750, TUV EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30~+60°C (Refer to "Derating Curve") PDF Datasheet HVGC-100-spec_4.pdf
