Wattage:
Voltage:
EAN:
Manufacturer:
Dimming:
DALI-2 (also DALI-1)
1-10V - 0-10V
CLO Function
DC EMERGENCY Function
Additional technical features:
RIPPLE FREE
ACTIVE PFC (pf>0.9)
SELV <>
DIMMING: AMPLITUDE (AM) IEEE1789-2015 - Dim-to-Warm
WIDE RANGE INPUT VOLTAGE
4/5 kV DM/CM SURGE Input Protection
Approvals:
ENEC
UL (class 2)
RCM
CE
EAC
UKCA
Plastic case:
Square
IP 20 (Independent Use)
ZHAGA AS1
Minimum cut-out hole diameter:
72 mm
Size:
103 x 21 x 67 mm
Current
300 mA
220-240 V = Output power
16.2 W
110-127 V =
15 W
Current
350 mA
220-240 V = Output power
18.9 W
110-127 V =
15 W
Current
400 mA
220-240 V = Output power
21.6 W
110-127 V =
15 W
Current
450 mA
220-240 V = Output power
24 W
110-127 V =
15 W
Current
500 mA
220-240 V = Output power
27 W
110-127 V =
15 W
Current
550 mA
220-240 V = Output power
29.7 W
110-127 V =
15 W
Current
600 mA
220-240 V = Output power
32.4 W
110-127 V =
15 W
Current
650 mA
220-240 V = Output power
35 W
110-127 V =
15 W
Current
700 mA
220-240 V = Output power
37.8 W
110-127 V =
15 W
Current
750 mA
220-240 V = Output power
38 W
110-127 V =
15 W
Current
800 mA
220-240 V = Output power
38 W
110-127 V =
15 W
Current
850 mA
220-240 V = Output power
38 W
110-127 V =
15 W
Current
900 mA
220-240 V = Output power
38 W
110-127 V =
15 W
Current
1000 mA
220-240 V = Output power
38 W
110-127 V =
15 W
Current
1050 mA
220-240 V = Output power
38 W
110-127 V =
15 W
