Wattage:
Voltage:
EAN:
Manufacturer:
Built-in 0~10Vdc and PWM signal dimming function
Output current level selectable by DIP switchProtections: Short circuit / Over voltage / Over temperature
Other features:
180~295VAC input only
Built-in active PFC function
Protections: Short circuit / Over voltage / Over temperature
Cooling by free air convection
Fully isolated plastic case
No load power consumption <0.5W
Class II power unit, no F.G.
Logarithm or linear dimming curve selectable (meet IEC62386-207)
Built-in 0~10Vdc and PWM signal dimming function
Power supplies synchronization function up to 10 units
Suitable for indoor LED lighting applications
3 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 25 Output Voltage Choose Option Dimmable (Type) 0~10Vdc & PWM signal Dimensions 105x 68x 23 EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 180~295VAC, 254~417VDC Safety Standards UL8750, ENEC EN61347-1, EN61347-2-13, EN62384 approved Output Voltage Options Single Working Temperature -40~+85°C PDF Datasheet LCM-25-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 25 Output Voltage Choose Option Dimmable (Type) 0~10Vdc & PWM signal Dimensions 105x 68x 23 EMC Standards EN55015, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547 Input Voltage 180~295VAC, 254~417VDC Safety Standards UL8750, ENEC EN61347-1, EN61347-2-13, EN62384 approved Output Voltage Options Single Working Temperature -40~+85°C PDF Datasheet LCM-25-SPEC.PDF
