Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Long lamp life
- No adverse effect from frequent on/off switching
- Automatic restart after lamp replacement
- Perfect lamp start for applications with motion sensors
- VDE/VDE EMC certified system
- Very high energy efficiency due to cut-off technology
Areas of application
- Open-plan offices, corridors and storage rooms
- Public buildings
- Strip lighting
- Suitable for emergency lighting (DC operation)
- Suitable for luminaires of protection class I
-
Technical Data
Electrical data
Input voltage AC
198…264 V
Nominal voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage DC
185…264 V
Maximum output power
2 x 70 W
Efficiency in full-load
91 %
Operating frequency
40…50 kHz
Max. ECG no. on circuit breaker 10 A (B)
8
Max. ECG no. on circuit breaker 16 A (B)
13
Inrush current
15 A
Light technical data
Starting time
2.0 s
Dimensions & weight
Length
360.0 mm
Width
30.0 mm
Height
28.0 mm
Mounting hole spacing, length
350.0 mm
Product weight
264.00 g
Cable cross-section, output side
0.5…1.5 mm²
Cable cross-section, input side
0.5…1.5 mm²
Temperatures & operating conditions
Ambient temperature range
-15…+50 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 h
Additional product data
Suitable for lamp power (2 lamps)
58…70 W
Capabilities
End of lamp life safety shutdown
EOL T.2
Suitable for fixtures with prot. class
I
Max. cable length to lamp/LED module
2.0 m / 1.0 m
Intended for no-load operation
No
Dimmable
No
Certificates & standards
Approval marks – approval
VDE / VDE-EMC / ENEC 10 / CE
EEI – Energy Label
A2
Standards
Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547
Type of protection
IP20
Protection class
I
Logistical data
Commodity code
850410809000
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)Date of Declaration
13-02-2022
Primary Article Identifier
4052899151932
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
59247456-2dea-40a9-b909-81746510b756
Packaging information
EAN
Unit
Piece
Dimension l x w x h
Weight
Volume
4052899151932 UNV
1 360mm x 30mm x 28mm 264.00g 0.30dm³ 4052899151949 VS
20 383mm x 159mm x 132mm 5442.00g 8.04dm³
