Built-in active PFC functionUniversal AC input (up to 305VAC) / Full RangeProtections: Short circuit/ Overload/ Over voltage/ Over temperatureOther features: Fully isolated plastic case with IP30 levelCooling by free air convectionIsolation class II, no F.G.Class 2 power unit5 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 16 Output Voltage 20V Dimmable (Type) No Dimensions 148 x 40 x 30 EMC Standards EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~305VAC; 127~431VDC Safety Standards Design refer to UL8750 ENEC EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+70°C (refer to output derating curve) PDF Datasheet LPF-16-spec_15.pdf
More Information Manufacturer Mean Well Output Wattage (W) 16 Output Voltage 20V Dimmable (Type) No Dimensions 148 x 40 x 30 EMC Standards EN55015, EN61547, EN61000-3-2 class C, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~305VAC; 127~431VDC Safety Standards Design refer to UL8750 ENEC EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -40~+70°C (refer to output derating curve) PDF Datasheet LPF-16-spec_15.pdf
