Wattage:
Voltage:
EAN:
Manufacturer:
Constant Voltage
Fully encapsulated with IP67 level
Protections: Short circuit/ Overload/ Over voltage
Other features:
Universal AC input / Full Range
Class 2 power unit
Isolation class II, no F.G.
Withstand 300VAC surge input for 5 seconds
Cooling by free air convection
Pass LPS
100% full load burn-in test
Low cost, High reliability
2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 35 Output Voltage 15V Dimmable (Type) No DC Output Adjustment N/A Dimensions 148 x 40 x 30 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards UL1310 approved; Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C PDF Datasheet LPV-35-SPEC.PDF
More Information Manufacturer Mean Well Output Wattage (W) 35 Output Voltage 15V Dimmable (Type) No DC Output Adjustment N/A Dimensions 148 x 40 x 30 EMC Standards EN55022 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11 Input Voltage 90~264VAC Safety Standards UL1310 approved; Design refer to TUV EN60950-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30°C~+70°C PDF Datasheet LPV-35-SPEC.PDF
