Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Flexible current setting (DIPswitch – 4 currents)
- Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
- High efficiency
- High quality of light thanks to low output ripple current
- Fulfil safety requirement due to overload, overtemperature, Hot Plug protection
Areas of application
- Linear lighting for office, education, industry, storage areas and retail
- Suitable for luminaires of protection class I
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
0/50/60 Hz
Input voltage AC
198…264 V
Current set
DipSwitch
Input voltage DC
176…276 V
Total harmonic distortion
< 10 %
Power factor λ
0.98
Device power loss
7.0 W
Inrush current
20 A
Max. ECG no. on circuit breaker 10 A (B)
16
Max. ECG no. on circuit breaker 16 A (B)
25
Max. ECG no. on circuit breaker 25 A (B)
-
Surge capability (L/N-Ground)
2 kV
Surge capability (L-N)
1 kV
Nominal output voltage
27…51 V
U-OUT (working voltage)
< 60 V
Nominal output current
800 / 900 / 975 / 1050 mA
Output current tolerance
±7.5 %
Output ripple current (100 Hz)
< 5 %
Output PSTLM
≤1
Output SVM
≤0.4
Nominal output power
21.6…53.6 W
Galvanic isolation
SELV
Dimensions & weight
Mounting hole spacing, length
270.0 mm
Product weight
217.00 g
Cable cross-section, input side
0.5…1.5 mm²
Cable cross-section, output side
0.5…1.5 mm²
Wire preparation length, input side
8.5…9.5 mm
Wire preparation length, output side
8.5…9.5 mm
Length
280.0 mm
Width
30.0 mm
Height
21.0 mm
Colors & materials
Casing material
Metal
Temperatures & operating conditions
Ambient temperature range
-25…+50 °C
Maximum temperature at tc test point
80 °C
Max.housing temperature in case of fault
110 °C
Temperature range at storage
-25…85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 / 100000 h
Capabilities
Dimmable
No
Overheating protection
Automatic reversible
Overload protection
Non-reversible
Short-circuit protection
Automatic reversible
No-load proof
Yes
Max. cable length to lamp/LED module
2.0 m
Suitable for fixtures with prot. class
I
Type of connection, output side
Push terminal
Number of channels
1
Programming
Programming device
DIPswitch
Certificates & standards
Approval marks – approval
CE / EL / ENEC 05 / EAC / CCC / RCM / BIS
Standards
Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 62384/Acc. to EN 61000-3-2/Acc. to EN 61000-3-3/Acc. to EN 61547
Protection class
I
Type of protection
IP20
Logistical data
Commodity code
850440829000
