Wattage:
Voltage:
EAN:
Manufacturer:
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
0/50/60 Hz
Input voltage AC
198…264 V
Input voltage DC
176…276 V
Total harmonic distortion
< 10 %
Power factor λ
0.95
ECG efficiency
88 %
Device power loss
2.4 W
Power loss in stand-by mode
≤0.27 W
Inrush current
5 A
Max. ECG no. on circuit breaker 10 A (B)
82
Max. ECG no. on circuit breaker 16 A (B)
130
Max. ECG no. on circuit breaker 25 A (B)
-
Surge capability (L/N-Ground)
2 kV
Surge capability (L-N)
1 kV
Nominal output voltage
7.5…54 V
U-OUT (working voltage)
60 V
Nominal output current
150…1050 mA
Output current LEDset open
75 mA
Output current LEDset shorted
350 mA
Default output current
350 mA
Output current tolerance
±3 %
Output ripple current (100 Hz)
< 2 %
Output PSTLM
≤1
Output SVM
≤0.4
Nominal output power
18 W
Galvanic isolation
SELV
Dimensions & weight
Product weight
100.00 g
Cable cross-section, input side
0.2…1.5 mm²
Cable cross-section, output side
0.2…1.5 mm²
Wire preparation length, input side
8.0…9.0 mm
Wire preparation length, output side
8.0…9.0 mm
Length
95.0 mm
Width
53.0 mm
Height
30.0 mm
Colors & materials
Casing material
Plastic
Temperatures & operating conditions
Ambient temperature range
-20…+50 °C
Maximum temperature at tc test point
75 °C
Max.housing temperature in case of fault
100 °C
Temperature range at storage
-25…85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 / 100000 h
Capabilities
Dimmable
Yes
Dimming interface
DALI / Touch DIM / Touch DIM Sensor
Dimming range
1…100 %
Dimming method
Amplitude Modulation
Constant lumen function
Programmable
Overheating protection
Automatic reversible
Overload protection
Automatic reversible
Short-circuit protection
Automatic reversible
No-load proof
Yes
Max. cable length to lamp/LED module
2.0 m
Suitable for fixtures with prot. class
I / II
Type of connection, output side
Push terminal
DALI-2 Diagnostic Data
Yes
Programming interface
DALI, LEDset
DALI-2 Energy Data
Yes
Number of channels
1
Programming
Programming device
DALI / LEDset
Tuner4TRONIC Field App
No
Programmable features
Lamp Operating Time
Yes
Driver Guard
No
DALI Settings
Yes
Emergency Mode
Yes
DALI-2 Luminaire Data
Yes
Configuration Lock
No
Soft Switch Off
Yes
Dim to Dark
No
TouchDIM + Sensor
Yes
Corridor Functionality
Yes
OEM Key
Yes
Certificates & standards
Approval marks – approval
ENEC 10 / VDE / EMC / EL / CE
Standards
Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384
Protection class
II
Type of protection
IP20
Logistical data
Commodity code
850440829000
