Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Fully programmable via software (DALI Interface)
- Flexible current setting (LEDset2)
- Lifetime: up to 100,000 h (temperature at Tc = 65 °C, max. 10 % failure rate)
- High-quality dimming of 1…100 % by amplitude dimming (except 80 W versions)
- High quality of light thanks to <1% output ripple current
- Very high efficiency
- Very low standby power consumption: < 0.25 W
- Fulfill safety requirement due to overload, overtemperature, Hot Plug protection
- Easy to use in corridors and restrooms because of three-level Corridor function
- Touch DIM application: easy to control via pushbutton or sensor
- Energy efficient Touch DIM operation due to automatic switch-off at sufficient residual light
- Suitable for emergency Installations (acc. to EN 60598-2-22 and IEC 61347-2-13, appendix J) thanks to DC detection (0 Hz, pulsating DC), on/off switchable
- Feedback of power consumption and operating hours (Fit for SMART GRID)
- Suitable for buildings according to EPBD/BREEAM/LEED due to automatic Constant Lumen Output setting
- Luminaire information for easy maintenance
Areas of application
- Linear lighting for office, education, industry, storage areas and retail
- Installation in emergency lighting systems according to IEC 61347-2-13, appendix J
- Suitable for luminaires of protection class I
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage AC
198…264 V
Input voltage DC
176…276 V
Current set
DALI / LEDset / Programmable
Total harmonic distortion
< 10 %
Power factor λ
> 0.95
Efficiency in full-load
92.5 %
Device power loss
5.0 W
Networked standby power
≤0.30 W
Inrush current
25 A
Max. ECG no. on circuit breaker 10 A (B)
15
Max. ECG no. on circuit breaker 16 A (B)
24
Max. ECG no. on circuit breaker 25 A (B)
37
Surge capability (L/N-Ground)
2 kV
Surge capability (L-N)
1 kV
Nominal output voltage
54…240 V
U-OUT (working voltage)
< 250 V
Nominal output current
120…550 mA
Output current LEDset open
60 mA
Output current LEDset shorted
120 mA
Default output current
60 mA
Output current tolerance
±3 %
Output ripple current (100 Hz)
< 1 %
Output PSTLM
≤1
Output SVM
≤0.4
Nominal output power
6.4…60 W
Maximum output power
60 W
Galvanic isolation
Non isolated
Dimensions & weight
Mounting hole spacing, length
270.0 mm
Product weight
205.00 g
Cable cross-section, input side
0.5…1.5 mm²
Cable cross-section, output side
0.5…1.5 mm²
Wire preparation length, input side
8.5…9.5 mm
Wire preparation length, output side
8.5…9.5 mm
Length
280.0 mm
Height
21.0 mm
Width
30.0 mm
Colors & materials
Casing material
Metal
Temperatures & operating conditions
Ambient temperature range
-25…+60 °C
Maximum temperature at tc test point
75 °C
Max.housing temperature in case of fault
110 °C
Temperature range at storage
-25…85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 / 100000 h
Additional product data
Encapsulated
No
Capabilities
Programming interface
DALI, LEDset
Dimmable
Yes
Dimming interface
DALI-2 / Touch DIM / Touch DIM Sensor
Dimming range
1…100 %
Dimming method
Full analogue dimming
Overheating protection
Automatic reversible
Overload protection
Automatic reversible
Short-circuit protection
Automatic reversible
No-load proof
Yes
Intended for no-load operation
No
Max. cable length to lamp/LED module
2.0 m
Suitable for fixtures with prot. class
I
Suitable for emergency lighting
Yes
Type of connection, input side
Push terminal
Type of connection, output side
Push terminal
DALI-2 Energy Data
Yes
Control interface
DALI
Number of channels
1
DALI-2 Diagnostic Data
Yes
Programming
Programming device
DALI magic
Tuner4TRONIC
Yes
Tuner4TRONIC Field App
Yes
Programmable features
DALI-2 Luminaire Data
Yes
Certificates & standards
Approval marks – approval
CE / EL / VDE-ENEC / VDE-EMC / EAC / CCC / BIS / RCM
Standards
Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 62386
Type of protection
IP20
Logistical data
Commodity code
850440829000
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration
23-12-2021
Primary Article Identifier
4052899188662 | 4052899315884 | 4052899494206 | 4062172082167
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
d8f69d0a-873d-4c9b-b472-095ce690d3dd | | 98e9d2e2-470f-4c61-8609-62ccc0499a93 | e06d8873-1ba2-4a16-a452-97f8720ce340
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
Volume |
|---|---|---|---|---|---|
| 4052899494206 | UNV
|
1 | 280mm x 30mm x 21mm | 205.00g | 0.18dm³ |
| 4052899494213 | VS
|
20 | 305mm x 161mm x 104mm | 4277.00g | 5.11dm³ |
