Wattage:
Voltage:
EAN:
Manufacturer:
Product family benefits
- Intelligent power matching thanks to Smart power supply
- Form factor for mounting on the cove or in luminaires
- No stroboscopic effect thanks to patented high PWM frequency management (> 2 kHz)
- Suitable for installation in emergency lighting systems according to EN 60598-2-22
- DALI message detection "LED Module failure"
- IP rating: IP20
Areas of application
- Cove lighting, wall washer, corridor, handrail, luminous ceilings
- Suitable for use in luminaires of protection class I and II
Equipment / Accessories
- Suitable for 24 V LED modules
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
50/60 Hz
Input voltage AC
198…264 V
Total harmonic distortion
< 5 %
Power factor λ
0.89C…0.99
Efficiency in full-load
93 %
Device power loss
6.0 W
Networked standby power
<0.50 W
Inrush current
46 A
Max. ECG no. on circuit breaker 10 A (B)
9
Max. ECG no. on circuit breaker 10 A (C)
15
Max. ECG no. on circuit breaker 16 A (B)
15
Max. ECG no. on circuit breaker 16 A (C)
25
Max. ECG no. on circuit breaker 25 A (B)
23
Surge capability (L-N)
1 kV
Nominal output voltage
24 V
U-OUT (working voltage)
24.2 V
Nominal output power
80 W
Maximum output power
80 W
Galvanic isolation
SELV
Galvanic isolation primary/secondary
3.75 kV
Output PWM frequency
> 2000 Hz
Input voltage DC
176…276 V
Output ripple Voltage (100 Hz)
< 1 %
Dimensions & weight
Mounting hole spacing, length
300.6 mm
Product weight
191.00 g
Cable cross-section, input side
0.5…2.5 mm²
Cable cross-section, output side
0.2…1.5 mm²
Wire preparation length, input side
6.0 mm
Wire preparation length, output side
5.0 mm
Width
32.0 mm
Height
22.0 mm
Length
346.0 mm
Colors & materials
Casing material
Plastic
Temperatures & operating conditions
Ambient temperature range
-20…+45 °C
Maximum temperature at tc test point
85 °C
Max.housing temperature in case of fault
115 °C
Temperature range at storage
-40…+85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 h
Additional product data
Predecessor EAN
4052899452893, 4052899490758
Capabilities
Dimmable
Yes
Dimming interface
DALI-2 / Touch DIM
Dimming range
0.1…100 %
Dimming method
Pulse Width Modulation
Overheating protection
Automatic reversible
Overload protection
Automatic reversible
Short-circuit protection
Automatic reversible
No-load proof
Yes
Intended for no-load operation
No
Suitable for fixtures with prot. class
I / II
Type of connection, input side
Screw terminal
Type of connection, output side
Screw terminal
Control interface
DALI-2
Number of channels
4
Programming
Tuner4TRONIC
Yes
Certificates & standards
Approval marks – approval
BIS / CCC / CE / EAC / EL / ENEC 10 / RCM / VDE / VDE-ENEC
Standards
Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 60598-2-22/Acc. to EN 62386/Acc. to EN 55015
Protection class
II
Type of protection
IP20
Logistical data
Commodity code
85044083900
Environmental information
Information according Art. 33 of EU Regulation (EC) 1907/2006 (REACh)
Date of Declaration
11-09-2023
Primary Article Identifier
4062172177924
Candidate List Substance 1
Lead
CAS No. of substance 1
7439-92-1
Safe Use Instruction
The identification of the Candidate List substance is sufficient to allow safe use of the article.
Declaration No. in SCIP database
306178cd-0651-46ba-a40e-ff061546e88f
Packaging information
EAN |
Unit |
Piece |
Dimension l x w x h |
Weight |
|---|---|---|---|---|
| 4062172177924 | UNV
|
1 | ||
| 4062172177931 | VS
|
20 | 370mm x 170mm x 113mm | 3998.00 |
