Wattage:
Voltage:
EAN:
Manufacturer:
Technical Data
Electrical data
Nominal input voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage AC
198…264 V
Input voltage DC
176…276 V
Current set
DALI / LEDset / Programmable
Total harmonic distortion
< 10 %
Power factor λ
> 0.95
ECG efficiency
up to 94 %
Device power loss
9.0 W
Power loss in stand-by mode
<0.25 W
Inrush current
25 A
Max. ECG no. on circuit breaker 10 A (B)
15
Max. ECG no. on circuit breaker 16 A (B)
24
Max. ECG no. on circuit breaker 25 A (B)
29
Surge capability (L/N-Ground)
2 kV
Surge capability (L-N)
1 kV
Nominal output voltage
54…240 V
U-OUT (working voltage)
< 250 V
Nominal output current
250…1000 mA
Output current LEDset open
125 mA
Output current LEDset shorted
250 mA
Default output current
125 mA
Output current tolerance
±3 %
Output ripple current (100 Hz)
< 1 %
Output PSTLM
≤1
Output SVM
≤0.4
Nominal output power
13.5…90 W
Galvanic isolation
Non isolated
Dimensions & weight
Mounting hole spacing, length
270.0 mm
Product weight
205.00 g
Cable cross-section, input side
0.5…1.5 mm²
Cable cross-section, output side
0.5…1.5 mm²
Wire preparation length, input side
8.5…9.5 mm
Wire preparation length, output side
8.5…9.5 mm
Height
21.0 mm
Width
30.0 mm
Length
280.0 mm
Colors & materials
Casing material
Metal
Temperatures & operating conditions
Ambient temperature range
-25…+50 °C
Maximum temperature at tc test point
75 °C
Max.housing temperature in case of fault
110 °C
Temperature range at storage
-25…85 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 / 100000 h
Additional product data
Encapsulated
No
Capabilities
Programming interface
DALI, LEDset
Dimmable
Yes
Dimming interface
DALI-2 / Touch DIM / Touch DIM Sensor
Dimming range
1…100 %
Dimming method
Full analogue dimming
Overheating protection
Automatic reversible
Overload protection
Automatic reversible
Short-circuit protection
Automatic reversible
No-load proof
Yes
Max. cable length to lamp/LED module
2.0 m
Suitable for fixtures with prot. class
I
Suitable for emergency lighting
Yes
Type of connection, input side
Push terminal
Type of connection, output side
Push terminal
Number of channels
1
Control interface
DALI
Programming
Tuner4TRONIC Field App
Yes
Programming device
DALI magic
Tuner4TRONIC
Yes
Certificates & standards
Approval marks – approval
CE / EL / VDE-ENEC / VDE-EMC / EAC / CCC / BIS / RCM
Standards
Acc. to EN 61347-1/Acc. to EN 61347-2-13/Acc. to EN 55015/Acc. to EN 61547/Acc. to EN 61000-3-2/Acc. to EN 62384/Acc. to EN 62386
Type of protection
IP20
