Wattage:
Voltage:
EAN:
Manufacturer:
AC phase-cut dimming
Works with leading edge and trailing edge TRIAC dimmers
Protections: Short circuit/ Over temperature
Other features:
180~295VAC input
Constant current design
Fully isolated plastic case
Built-in active PFC function
IP30 design
Class 2 power unit/ Pass LPS
Isolation class II"
Cooling by free air convection
3 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 40 Output Current 1750mA Dimmable (Type) AC phase-cut Output Voltage Range (V) 13~23 Dimensions 128x 60x 31.5 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A Input Voltage 180~295VAC Safety Standards UL8750, ENEC EN61347-1, EN61347-2-13 independent, IP30 approved Output Voltage Options Single Working Temperature -30~+50°C (refer to output derating curve) PDF Datasheet PCD-40-spec_21.pdf
More Information Manufacturer Mean Well Output Wattage (W) 40 Output Current 1750mA Dimmable (Type) AC phase-cut Output Voltage Range (V) 13~23 Dimensions 128x 60x 31.5 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2,3,4,5,6,8,11, EN61547, light industry level (surge 4KV), criteria A Input Voltage 180~295VAC Safety Standards UL8750, ENEC EN61347-1, EN61347-2-13 independent, IP30 approved Output Voltage Options Single Working Temperature -30~+50°C (refer to output derating curve) PDF Datasheet PCD-40-spec_21.pdf
