Wattage:
Voltage:
EAN:
Manufacturer:
Constant current designBuilt-in active PFC functionProtections: Short circuitOther features:Universal input/ Full range (110~295VAC)No load power consumption <0.5WCooling by free air convectionFully isolated plastic caseSmall and compact sizeClass II power unit, no FG100% full load burn-in testHigh reliability, low costSuitable for LED lighting and moving sign applications2 years warranty
More Information Manufacturer Mean Well Output Wattage (W) 25 Dimmable (Type) No Output Voltage Range (V) 14.4~36 Dimensions 145x 38x 22 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547, light industry level (surge 2KV), criteria B Input Voltage 110~295VAC, 156~417VDC Safety Standards Design refer to EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30~+50°C PDF Datasheet PLM-25-spec_1.PDF
More Information Manufacturer Mean Well Output Wattage (W) 25 Dimmable (Type) No Output Voltage Range (V) 14.4~36 Dimensions 145x 38x 22 EMC Standards Compliance to EN55015, EN61000-3-2 Class C; EN61000-3-3, EN61000-4-2, 3, 4, 5, 6, 8, 11; EN61547, light industry level (surge 2KV), criteria B Input Voltage 110~295VAC, 156~417VDC Safety Standards Design refer to EN61347-1, EN61347-2-13 Output Voltage Options Single Working Temperature -30~+50°C PDF Datasheet PLM-25-spec_1.PDF
