Wattage:
Voltage:
EAN:
Manufacturer:
Electrical data
Input voltage AC
198…264 V
Nominal voltage
220…240 V
Mains frequency
50…60 Hz
Input voltage DC
176…276 V
Operating frequency
40…50 kHz
Max. ECG no. on circuit breaker 10 A (B)
17
Max. ECG no. on circuit breaker 16 A (B)
28
Light technical data
Starting time
1.0 s
Dimensions & weight
Length
103.0 mm
Width
67.0 mm
Height
31.0 mm
Mounting hole spacing, length
94.0 mm
Mounting hole spacing, width
57.0 mm
Product weight
148.50 g
Cable cross-section, input side
0.5…1.5 mm²
Cable cross-section, output side
0.5…1.5 mm²
Temperatures & operating conditions
Ambient temperature range
-20…+50 °C
Permitted rel. humidity during operation
5…85 %
Lifespan
ECG lifetime
50000 h
Additional product data
Suitable for lamp power (2 lamps)
26 W
Product remark
Optional cable clamp, see chapter ECG mountings - cable clamp
Suitable for lamp power (1 lamp)
26…42 W
Capabilities
End of lamp life safety shutdown
EOL T.2
Suitable for fixtures with prot. class
I / II
Dimmable
No
Max. cable length to lamp/LED module
2.0 m / 1.0 m
Certificates & standards
Approval marks – approval
VDE / ENEC 10 / VDE-EMC / GOST / RCM
EEI – Energy Label
A2 BAT
Standards
Acc. to EN 61347-2-3/Acc. to EN 60929/Acc. to EN 55015:2006 + A1:2007/Acc. to EN 61000-3-2/Acc. to EN 61547
Type of protection
IP20
Protection class
